Product Advantage
1. NBR rubber gasket are made of new high-quality nitrile rubber and produced through compression molding process. The cross-section is usually circular, but can also be designed into any shape according to requirements. It has high precision, with a minimum size error of only 0.05mm. The surface is smooth, flat, without any burrs, cracks, or debris.
2. NBR rubber gasket has excellent wear resistance. It is the cheapest static fixed seal and buffer seal. It has high friction, good sealing, long service life and good resilience, its minimum tensile strength is up to 20Mpa.
3. NBR rubber gasket has excellent oil resistance. Its core performance depends on the acrylonitrile content, and the higher the content, the better the oil resistance and wear resistance. It has good resistance to petrochemical oil and hydrocarbon fuel oil. Commonly used in hydraulic seal, fuel seal, and static seal to prevent oil leakage.
4. NBR rubber gasket is the cheapest gasket, besides being used as a rubber seal, it can also be used for buffering between machinery. Oil resistant and wear-resistant NBR rubber gasket is often paired with oil seals and appear in OEM automotive parts.
Item | Unit | NBR Gasket | |
Normal Condition | Color | / | Black,Green |
Hardness | Shore A | 40—90 | |
Tensile Strength | MPa | 10.6—21.3 | |
Elongation | % | 150—672 | |
Compression Set (100℃/22h) | % | 8—35 | |
Hot Air Aging (100℃/70h) | Hardness Change | Shore A | 2—6 |
Tensile Strength Change | % | -5—21 | |
Elongation Change | % | -9—-32 | |
Oil Resistance Test (IRM901#) (100℃/70h) | Hardness Change | Shore A | 1—8 |
Tensile Strength Change | % | -2—26 | |
Elongation Change | % | -8—-35 | |
Volume Change | % | -1—-4 | |
Oil Resistance Test (IRM903#) (100℃/70h) | Hardness Change | Shore A | -1—-8 |
Tensile Strength Change | % | -2—22 | |
Elongation Change | % | -10—23 | |
Volume Change | % | 0—12 | |
Low Temperature Resistance Test | Brittle Temperature | ℃ | -35—-50 |
Nitrile Rubber (NBR)
Temperature Range: -30 °C to 125 °C
Advantage: Excellent oil and water
Disadvantage: Substandard cold resistance
Use: Oil & Water resistance situation
Here are specific application scenarios for NBR rubber gaskets:
1. Automotive industry: used in engine, fuel tank, and lubrication tank systems to prevent leakage of liquids such as oil and fuel. Used as oil pan seal, valve cover seal, cylinder head seal, shaft seal, and oil filter seal.
2. Fuel system: Connect the fuel pump, fuel rail, and injectors to prevent high-pressure fuel leakage and ensure the sealing of the fuel tank and fuel pipes.
3. Industrial Machinery and Hydraulic Systems: Used for sealing pumps, compressors, valves, pressure vessels, and pipeline and equipment connections in industrial machinery, and for sealing hydraulic cylinders, valves, pumps, and other components in hydraulic systems.
4. General field: Any rubber seal usage environment without special requirements.
Q1. What sizes do you have?
A: We have all sizes of AS568 standard and JIS B 2401standard, and about 3000 non-standard sizes, we also can produce the size according to your requirement.
Q2. Do you have any certificates?
A: We have IATF16949:2016 certificate, ROHS certificate, PAHS certificate, REACH certificate and FDA certificate.
Q3. Can I get some samples before order?
A: Yes, we can provide free samples. You only need to pay for the freight.
Q4. What is the lead time?
A: The lead time for samples is 1-3 days. The lead time for mold is 1-2 weeks. The lead time for batch order is 1-3 weeks.
