Product Advantage
1. EPDM gaskets are inexpensive and have a long service life. In the long run, their cost-effectiveness is even higher than the cheapest NBR rubber gaskets.
2. EPDM gaskets have excellent weather resistance. It can resist natural environmental erosion and keep its original performance for a long time. It has good stability against sunlight, ozone, daily temperature changes, and daily moisture and humidity. Its surface will not crack after being exposed to high concentration ozone for more than 2400 hours. It is the best choice for outdoor rubber gaskets. The outdoor service life is up to 25 years.
3. It has a saturated double chain formed by the polymerization of ethylene and propylene, so its chemical properties are stable. It has good resistance to polar solvents and weak acids and bases, such as water, alcohols, ketones, and lipids.
4. It has good resistance to high temperature steam and good impermeability to gases. Its molecular chains are tightly stacked together, greatly reducing the microchannels required for gas molecule permeation. And it has a very low glass transition temperature, and its molecular chains are in a highly flexible rubber state at room temperature.
Item | Unit | EPDM Gasket | |
Normal Condition | Color | / | Black,Yellow,Purple |
Hardness | Shore A | 30—90 | |
Tensile Strength | MPa | 9.6—14.7 | |
Elongation | % | 110—438 | |
Compression Set (100°C/22h) | % | 40—51 | |
Hot Air Aging (70°C/70h) | Hardness Change | Shore A | 3—5 |
Tensile Strength Change | % | -2—8 | |
Elongation Change | % | -29—-38 | |
Oil Resistance Test (IRM901#)(150°C/70h) | Hardness Change | Shore A | / |
Tensile Strength Change | % | / | |
Elongation Change | % | / | |
Volume Change | % | / | |
Oil Resistance Test (IRM903#)(150°C/70h) | Hardness Change | Shore A | / |
Tensile Strength Change | % | / | |
Elongation Change | % | / | |
Volume Change | % | / | |
Low Temperature Resistance Test | Brittle Temperature | °C | -55—-100 |
Ethylene Propylene Rubber (EPDM)
Temperature Range: -50 °C to 150 °C
Advantage: Excellent ozone and ageing resistance, excellent water-proof function
Disadvantage: Substandard polar solvent resistance
Use: Ozone, water vapor situation
Here are specific application scenarios for EPDM gaskets:
1. Automotive industry: Used for water tank seal, sensor seal, pump seal, and pipe seal in the cooling system of automobiles or electric vehicles. The extremely long service life of EPDM rubber gaskets can almost be used for the entire automotive life.
2. Chemical industry: Used for transporting chemicals such as alcohols, ketones, dilute acids, and bases, playing a sealing role in the production and transportation of these chemicals.
3. Food industry: Used in the food processing industry with weak acidity and alkalinity, such as milk, coffee, juice, or in the brewing process of wine, beer, and other fermented alcoholic beverages for seal.
Q1. What sizes do you have?
A: We have all sizes of AS568 standard and JIS B 2401standard, and about 3000 non-standard sizes, we also can produce the size according to your requirement.
Q2. Do you have any certificates?
A: We have IATF16949:2016 certificate, ROHS certificate, PAHS certificate, REACH certificate and FDA certificate.
Q3. Can I get some samples before order?
A: Yes, we can provide free samples. You only need to pay for the freight.
Q4. What is the lead time?
A: The lead time for samples is 1-3 days. The lead time for mold is 1-2 weeks. The lead time for batch order is 1-3 weeks.
